GRW610-W890
ATX, 6th Generation Intel® Xeon® W Family, DDR5 ECC-RDIMM, DP, OOB, 3 PCIe x16 (Gen5), 4 PCIe x8 (Gen5), 2 M.2 M key 2280, 2 2.5GbE + 2 10GbE, 8 SATA 3.0, 8 USB 3.2, 2 USB 2.0, 1 Vertical USB 2.0, 7 COM, 1 Dedicated IPMI, Intel® W890 Chipset
- 6th Generation Intel® Xeon® W Family
- 8 DDR5 ECC-RDIMM up to 1024GB
- IPMI/Redfish OOB Remote Management
- Single Display: DP
- Multiple Expansion: 3 PCIe x16 (Gen5), 4 PCIe x8 (Gen5), 2 M.2 M key 2280
- Rich I/O: 2 2.5GbE + 2 10GbE, 8 SATA 3.0, 8 USB 3.2, 2 USB 2.0, 1 Vertical USB 2.0, 7 COM, 1 Dedicated IPMI
Főbb jellemzők
Tanúsítványok
#M.2
#6th Generation Intel® Xeon® W Family
#Intel
#PCIe x16
#DP
#Multiple Expansion
#10G Ethernet
#RoHS Certification
#CE Certification
#FCC Certification
#Service Robot
#2.5G Ethernet
Főbb jellemzőkKey features
- 6th Generation Intel® Xeon® W Family
- 8 DDR5 ECC-RDIMM up to 1024GB
- IPMI/Redfish OOB Remote Management
- Single Display: DP
- Multiple Expansion: 3 PCIe x16 (Gen5), 4 PCIe x8 (Gen5), 2 M.2 M key 2280
- Rich I/O: 2 2.5GbE + 2 10GbE, 8 SATA 3.0, 8 USB 3.2, 2 USB 2.0, 1 Vertical USB 2.0, 7 COM, 1 Dedicated IPMI
System
- Processor
- 6th Generation Intel® Xeon® W Family, LGA4710 Socket, TDP upto 350W: Intel® Xeon® 696X Processor (64 Cores, 336 MB Cache, up to 4.8 GHz); 350W Intel® Xeon® 674X Processor(28 Cores, 144 MB Cache, up to 4.9 GHz); 270W Intel® Xeon® 658X Processor(24 Cores, 144 MB Cache, up to 4.9 GHz); 250W Intel® Xeon® 634 Processor (12 Cores, 48 MB Cache, up to 4.6 GHz); 150W
- Chipset
- Intel® W890 Chipset
- Memory
- 8 x ECC-RDIMM up to 1024GB (630 series only support 4 dimms up to 512GB) DDR5 Max. 6400MHz
- BIOS
- Insyde
Graphics
- Controller
- BMC AST2600
- Display
- 1 x DP
- Single Display
- DP
Expansion
- PCIe
- 3 x PCIe x16 (Gen5) 4 x PCIe x8 (Gen5) - (630 series no support #2) 2 x M.2 M key 2280
Audio
- Audio Codec
- ALC888S
Ethernet
- Controller
- 1 x Intel® I226LM + 1 x Intel® I226V + 2 x Intel® E610-XAT2 IPMI: RTL8211F
Rear I/O
- Ethernet
- 2 x 2.5GbE + 2 x 10GbE 1 x Dedicated IPMI LAN
- Serial
- 1 x RS-232/422/485 (DB-9)
- USB
- 6 x USB 3.2 Gen1
- Display
- 1 x DP
Internal I/O
- Serial
- 4 x RS-232/422/485
- USB
- 2 x USB 3.2 Gen1 2 x USB 2.0 1 x Vertical USB 2.0
- Audio
- 1 x Front Audio
- SATA
- 8 x SATA 3.0 RAID 0/1/5/10
- DIO
- 16-bit DIO
- Fan
- 1 x CPU fan + 5 x System fan
- MCIO
- 6 x MCIO
- PMBUS
- 1 x PMBUS
- UID
- UID-LED header
Security
- TPM
- TPM 2.0
Power
- Type
- ATX
Environment
- Temperature
- Operating: 0 to 60°C
Mechanism
- Dimensions
- 305 x 267 mm
- Height
- PCB: TBD Top Side: TBD Bottom Side: TBD
Standards and Certifications
- Certifications
- CE, FCC, RoHS, UKCA
Packing List
- Packing List
- •GRW610-W890 Motherboard, 770-GRW6101-000G •2 M.2 screw, A32-112016-041G •2 M.2 standoff, A33-725019-090G •1 IO Shield, A49-GRW610-000G •1 Serial ATA data cable (Length: 500mm), 332-553001-005G •1 COOLER CARRIER
Country of Origin
- Country of Origin
- Taiwan
