PRT193
Mini-ITX, AMD Ryzen AI P100 Series Processors, DDR5, 4 DP2.0, 1 PCIE Gen4 x16, 1 M.2 M key, 2 2.5GbE RJ45, 2 USB 3.2 Type-A, 2 USB2.0 Type A, 2 COM D-Sub, 1 Audio Jack Line-in/Line-out/Mic-in, 4 RS232, 4 USB 2.0, Gaming I/O (PCIE,UART/USB2.0,Audio), -5 to 65°C
- AMD® Ryzen™ AI P100 Series Processors
- 2 DDR5 5600MHz SODIMM up to 64GB
- Quad display: 4 DP2.0
- Multiple expansion: 1 PCIE Gen4 x16 Slot (x8 Signal), 1 M.2 M key (PCIE/SATA)
- Rich IO :2 2.5GbE RJ45, 2 USB 3.0 Type- A, 2 USB2.0 Type A, 2 COM D-Sub,1 Audio Jack Line-IN/Line-OUT/Mic-IN, 4 RS232(ccTalk/TTL), 4 USB2.0 headers, Gaming I/O(PCIE,UART/USB2.0,Audio)
Főbb jellemzők
Tanúsítványok
#DDR5
#Edge AI Computing
#I2C
#12~24V DC-in
#AMD® Ryzen™ AI P100 Series Processors
#AI
#AMD
#PCIe x16
#Windows
#Linux
#DP
#Multiple Expansion
#RoHS Certification
#CE Certification
#FCC Certification
#Gaming
#2.5G Ethernet
Főbb jellemzőkKey features
- AMD® Ryzen™ AI P100 Series Processors
- 2 DDR5 5600MHz SODIMM up to 64GB
- Quad display: 4 DP2.0
- Multiple expansion: 1 PCIE Gen4 x16 Slot (x8 Signal), 1 M.2 M key (PCIE/SATA)
- Rich IO :2 2.5GbE RJ45, 2 USB 3.0 Type- A, 2 USB2.0 Type A, 2 COM D-Sub,1 Audio Jack Line-IN/Line-OUT/Mic-IN, 4 RS232(ccTalk/TTL), 4 USB2.0 headers, Gaming I/O(PCIE,UART/USB2.0,Audio)
System
- Processor
- AMD Ryzen AI P100 Series Processors
- Memory
- 2 x 262-pin dual-channel SODIMM DDR5 5600MHz with ECC/non-ECC support up to 64GB (32GB per Dimm)
- BIOS
- AMI SPI 256Mbit
Graphics
- Controller
- RDNA3.5 graphics with up to 8 WGPs (Work Group processors)
- Display
- DP2.0
- Quad Displays
- 4 x DP2.0
Expansion
- M.2
- 1 x M.2 M Key 2280 slot (PCIE Gen4 x4)
- PCIe
- 1 x PCIE Gen4 x16 slot (x8 Signal)
- Gaming I/O
- GIO1 (UART, USB2, AUDIO R/L) GIO2 (PCIE x1)
Audio
- Audio Codec
- 1 x Realtek ALC888S
Ethernet
- Controller
- 2 x Intel I226-V (10/100/1000/2500 Mbps)
Rear I/O
- Ethernet
- 2 x 2.5GbE (RJ-45)
- Serial
- 1 x Full RS232 1 x RS232/RS422/RS485
- USB
- 2 x USB 3.2 Type A 2 x USB 2.0 Type A
- Display
- 4 x DP++ display
- Audio
- 1 x Front audio (Line-out, Line-in, Mic-in)
Internal I/O
- Serial
- 2 x RS232 / TTL header 2 x RS232 / ccTalk header
- USB
- 4 x USB 2.0 port (pitch 2.0mm) 1 x USB 2.0 vertical Type A
- Audio
- 1 x S/PDIF (audio in & out) (Signal from ALC888S)
- SATA
- 2 x SATA3 (6Gb/s) 2 x SATA Power
- DIO
- 1 x 8-bit header with power
- SMBus/ I2C
- 2 x I2C 1 x SPI
- Case Open
- 1 1x2p header
Watchdog Timer
- Output & Interval
- System Reset, Programmable via Software from 1 to 255 Seconds
Security
- TPM
- dTPM 2.0(Default), fTPM (Option)
Power
- Type
- Single 12~24V +/-5% DC
- Connector
- DC-in Jack (Request) Straight Type Connector (4-pin) (Default)
- Consumption
- TBD
- RTC Battery
- CR2032 coin cell
OS Support
- Microsoft
- Windows 11 22H2 GAC Windows 11 LTSC
- Linux
- Ubuntu 22.04
Environment
- Temperature
- Operating: -5 to 65°C Storage: -40 to 85°C
- Humidity
- 10 to 90% RH
- MTBF
- TBD
Mechanism
- Dimensions
- Mini-ITX Form Factor 170mm (6.7") x 170mm (6.7")
- Height
- PCB: 1.6mm Top Side: TBD Bottom Side: TBD
Standards and Certifications
- Certifications
- CE, FCC, RoHS
Packing List
- Packing List
- • 1 motherboard • 1 I/O shield, TBD
Country of Origin
- Country of Origin
- Taiwan
